1mm Jobber Drill Bit | Lyndon, HSS, DIN 338, 135° Split Point

£1.24 (inc. VAT: £1.49)

High quality general purpose 1mm high speed steel HSS engineering jobber drill bit. Lyndon LD/010, 34mm/12mm ground flute, 135° split point, 1N/mm².

14 in stock (can be backordered)

SKU: JDM0100HSS Category:

Description

These 1.00mm general purpose jobber drill bits from Lyndon (MPN: LD/010) deliver on the high quality standards expected by professionals. The ground flute is ideal for demanding applications where accuracy and a smooth cut are important, while the 135° split point self-centers and prevents wandering to further increase your precision without requiring a pilot hole.

These drill bits are sharp and cut fast requiring minimal downward force making it easier to work with harder materials. They have a tensile strength of up to 1.000 N/mm² and can be used on a variety of materials such as: cast steel, alloy steel, carbon steel, hardened alloy steels, stainless steel, grey cast iron, malleable cast iron, nickel brass, graphite, plastic and wood.

Suitable for use with power tools and drilling machines. Made to the DIN 388 standard.

Diameter 1.00mm
Flute Length 12mm
Shank Length 46mm
Overall Length 34mm
Material High Speed Steel (HSS)
Flute Ground Flute
Point 135° Split Point

Additional information

Weight 0.001667 kg
Dimensions 3.4 × 0.1 × 0.1 cm
Brand

Lyndon

Drill Bit Type

Jobber

Drill Bit Series

Regular

Drill Bit Diameter

M1

Flute Type

Ground Flute

Flute Length

12mm

Shank Length

46mm

Overall Length

34mm

Point Type

135° Split Point

Material

HSS (High Speed Steel)
