Description
Recommended tapping drill size = 6.8mm
Threadsize (D) = M8 x 1.25
Overall Length (L1) = 72mm
Working Length (L2) = 22mm
Shaft Diameter (D2) = 8.0mm
Drive Square Size (□) = 6.3mm
Spiral point for through holes
Use with non abrasive material up to 900 N/mm2, unalloyed and low alloyed steel
Highest quality European manufactured
Metric ISO-thread DIN 13
ISO 529
HSS-G
Tolerance ISO2/6H
TiN coating available on some sizes – resists wear and minimises friction to allow increased cutting speeds
